EKD6-PM32R DC Isolator suitable for panel mounting

EKD6-PM32R DC Isolator suitable for panel mounting

EKD6-PM32R Series isolator Parallel wiring, larger aperture, much easier wiring.Suitable for panel mounting.Arc extinction time less than 3ms.Modular design. 2 poles & 4poles optional.The handle locked in "OFF" position.Comply with IEC60947-3(ed.3.2):2015,DC-PV1standard.

Inquire NOW PDF
EKD6-PM32R DC Isolator suitable for panel mounting

EKD6-PM32R DC Isolator suitable for panel mounting

Inquire NOW PDF

Product Profile

A DC isolator switch is an electrical safety device that manually disconnects itself from the modules in a solar PV system. In PV applications, DC isolator switches are used to manually disconnect the solar panels for maintenance, installation or repair purposes.

In most solar PV installations, two DC isolator switches are connected to a single string. Normally, one switch is placed close to the PV array and the other close to the DC end of the inverter. This is to ensure that disconnection can be achieved at ground and roof level. DC isolators can come in polarized or non-polarized configurations. For DC isolator switches that are polarized, they come in two, three and four pole configurations.

Technical Data

Utilization category DC-PV1/DC-PV2

Series

No.of Strings

Part Number

Contact Configuration

500V

600V

700V

800V

900V

1000V

1200V

1500V

32

32

32

32

23

16

13

7

2

1

EKD6-PM32R-2

ekd6 pm32r enclosure dc isolator 2

58

58

58

45

23

16

13

7

4

1

EKD6-PM32R-2H

ekd6 pm32r enclosure dc isolator 3

32

32

32

32

23

16

113

7

2

2

EKD6-PM32R-4

ekd6 pm32r enclosure dc isolator 4

32

32

32

32

32

32

32

23

4

1

EKD6-PM32R-4S

ekd6 pm32r enclosure dc isolator 5

32

32

32

32

32

32

32

23

4

1

EKD6-PM32R-4B

ekd6 pm32r enclosure dc isolator 6

32

32

32

32

32

32

32

23

4

1

EKD6-PM32R-4T

ekd6 pm32r enclosure dc isolator 7



ekd6 el32 renclosure dc isolator 8



Main Parameters

PM32R

Rated insulation voltage Ui

1500V

Rated thermal current Ithe

32A

Rated impulse withstand voltage Uimp

8000V

Rated short-circuit making capacity Icm

2H

1700A

2,4

1000A

2H

1700A

Rated conditional short-circuit current Icc

5000A

Max. fuse size gL (gG)

80A

Maximum cable cross sections (incl. jumper)
Solid or standard  mm2 4-16
Flexible 4-10
Flexible (+ multicore cable end) 4-10
Torque
Tightening torque terminal screws M4. Nm 1.2-1.8
Tightening torque panel mounting screws ST4.2(304 stainless steel) 0.8-0.9
Tightening torque knob screws M3 0.5-0.7
Switching on or off torque 0.9-1.3
General parameters
Method of mounting Single Hole Mounting
Type of knob C
ekd6 pm32r enclosure dc isolator 9
Knob positions OFF at 12 hr, ON at 3 hr
Mechanical life 10000
Number of DC poles 2 or 4
Operation temperature -40℃ to +70℃
Storage temperature -40℃ to +85℃
Pollution degree 2
Overvoltage category III
IP rating of shafte and mounting nut IP66

Dimensions

ekd6 pm32r enclosure dc isolator 10

Product selection form

Reference No. Specification
EKD6-PM32R-2 DC Isolator 2P 32A 2series
/1strings Top to Bottom Connection Red/Yellow Colour PL64
EKD6-PM32R-2H DC Isolator 4P 32A 4series
/1strings Top to Bottom Connection Red/Yellow Colour PL64
EKD6-PM32R-4 DC Isolator 4P 32A 4series
/2strings Red/Yellow Colour PL64
EKD6-PM32R-4S DC Isolator 4P 32A 4series
/1(3+1) string Top to Bottom Connection Red/Yellow Colour PL64
EKD6-PM32R-4B DC Isolator 4P 32A 4series
/1(2+2) string Bottom Connection Red/Yellow Colour PL64
EKD6-PM32R-4T DC Isolator 4P 32A 4series
/1(2+2) strings Top Connection Red/Yellow Colour PL64
