EKDB8 Plastic Distribution Box

EKDB8 Plastic Distribution Box

The Distribution Box is used for Terminal power distributing system

Inquire NOW PDF
EKDB8 Plastic Distribution Box
EKDB8 Plastic Distribution Box

EKDB8 Plastic Distribution Box

Inquire NOW PDF
Product Profile
Dimensions
Product selection form
Recommended products
Inquiry

Product Profile

Electrical Rating 63-1250A, Single phase/Three phase, 240/415V AC 50/60Hz
Protection Degree IP65
Material Steel
Installation Method Surface-Mounted

Dimensions

Product selection form

Model No. Size(mm) Thickness(mm) Bottom hole size Lock QTY Mounting plate size(mm)
Model Code H W D Door Body M.P L M
EKDB8 2020/15 610001 200 200 150 1.2 1.2 2 A 1 150 150
EKDB8 2520/15 610002 250 200 150 1.2 1.2 2 A 1 250 150
EKDB8 3020/15 610003 300 200 150 1.2 1.2 2 A 1 250 150
EKDB8 3020/20 610004 300 200 200 1.2 1.2 2 A 1 250 150
EKDB8 3025/15 610005 300 250 150 1.2 1.2 2 A 1 250 200
EKDB8 3025/20 610006 300 250 200 1.2 1.2 2 A 1 250 200
EKDB8 3030/15 610007 300 300 150 1.2 1.2 2 B 1 250 250
EKDB8 3030/20 610008 300 300 200 1.2 1.2 2 B 1 250 250
EKDB8 3030/25 610009 300 300 250 1.2 1.2 2 B 1 250 250
EKDB8 4030/15 610010 400 300 150 1.2 1.2 2 B 1 350 250
EKDB8 4030/20 610011 400 300 200 1.2 1.2 2 B 1 350 250
EKDB8 4030/25 610012 400 300 250 1.2 1.2 2 B 1 350 250
EKDB8 4030/30 610013 400 300 300 1.2 1.2 2 B 1 350 250
EKDB8 4040/15 610014 400 400 150 1.2 1.2 2 C 1 350 250
EKDB8 4040/20 610015 400 400 200 1.2 1.2 2 C 1 350 350
EKDB8 4040/25 610016 400 400 250 1.2 1.2 2 C 1 350 350
EKDB8 4040/30 610017 400 400 300 1.2 1.2 2 C 1 350 350
EKDB8 5030/15 610018 500 300 150 1.2 1.2 2 B 1 450 350
EKDB8 5030/20 610019 500 300 200 1.2 1.2 2 B 1 450 250
EKDB8 5030/25 610020 500 300 250 1.2 1.2 2 B 1 450 250
EKDB8 5040/15 610021 500 400 150 1.2 1.2 2 C 1 450 350
EKDB8 5040/20 610022 500 400 200 1.2 1.2 2 C 1 450 350
EKDB8 5040/25 610023 500 400 250 1.2 1.2 2 C 1 450 350
EKDB8 5040/30 610024 500 400 300 1.2 1.2 2 C 1 450 350
EKDB8 5050/20 610025 500 500 200 1.2 1.2 2 D 1 450 450
EKDB8 5050/25 610026 500 500 250 1.2 1.2 2 D 1 450 450
EKDB8 5050/30 610027 500 500 300 1.2 1.2 2 D 1 450 450
EKDB8 6040/15 610028 600 400 150 1.2 1.2 2 C 2 550 350
EKDB8 6040/20 610029 600 400 200 1.2 1.2 2 C 2 550 350
EKDB8 6040/25 610030 600 400 250 1.2 1.2 2 C 2 550 350
EKDB8 6040/30 610031 600 400 300 1.2 1.2 2 C 2 550 350
EKDB8 6050/15 610032 600 500 150 1.2 1.2 2 D 2 550 450
EKDB8 6050/20 610033 600 500 200 1.2 1.2 2 D 2 550 450
EKDB8 6050/25 610034 600 500 250 1.2 1.2 2 D 2 550 450
EKDB8 6050/30 610035 600 500 300 1.2 1.2 2 D 2 550 450
EKDB8 6060/15 610036 600 600 150 1.2 1.2 2 D 2 550 550
EKDB8 6060/20 610037 600 600 200 1.2 1.2 2 D 2 550 550
EKDB8 6060/25 610038 600 600 250 1.2 1.2 2 D 2 550 550
EKDB8 6060/30 610039 600 600 300 1.2 1.2 2 D 2 550 550
EKDB8 7050/15 610040 700 500 150 1.2 1.2 2 D 2 650 450
EKDB8 7050/20 610041 700 500 200 1.2 1.2 2 D 2 650 450
EKDB8 7050/25 610042 700 500 250 1.2 1.2 2 D 2 650 450
EKDB8 7060/20 610043 700 600 200 1.2 1.2 2 D 2 650 550
EKDB8 7060/25 610044 700 600 250 1.2 1.2 2 D 2 650 550
EKDB8 7060/30 610045 700 600 300 1.5 1.5 2 D 2 650 550
EKDB8 8060/20 610046 800 600 200 1.5 1.5 2 D 2 750 550
EKDB8 8060/25 610047 800 600 250 1.5 1.5 2 D 2 750 550
EKDB8 8060/30 610048 800 600 300 1.5 1.5 2 D 2 750 550
EKDB8 8080/20 610049 800 800 200 1.5 1.5 2 F 2 750 750
EKDB8 8080/25 610050 800 800 250 1.5 1.5 2 F 2 750 750
EKDB8 8080/30 610051 800 800 300 1.5 1.5 2 F 2 750 750
EKDB8 10060/20 610052 1000 600 200 1.5 1.5 2 D 2 950 550
EKDB8 10060/25 610053 1000 600 250 1.5 1.5 2 D 3 950 550
EKDB8 10060/30 610054 1000 600 300 1.5 1.5 2 D 3 950 550
EKDB8 10070/20 610055 1000 700 200 1.5 1.5 2 D 3 950 650
EKDB8 10080/20 610056 1000 800 200 1.5 1.5 2 F 3 950 750
EKDB8 10080/25 610057 1000 800 250 1.5 1.5 2 F 3 950 750
EKDB8 10080/30 610058 1000 800 300 1.5 1.5 2 F 3 950 750
EKDB8 10080/40 610059 1000 800 400 1.5 1.5 2 F 3 950 750
EKDB8 100100/25 610060 1000 1000 250 1.5 1.5 2 G 3 950 950
EKDB8 100100/30 610061 1000 1000 300 1.5 1.5 2 G 3 950 950
EKDB8 12060/20 610062 600 600 20 1.5 1.5 2 D 3 1150 550
EKDB8 12060/25 610063 600 600 250 1.5 1.5 2 D 3 1150 550
EKDB8 12060/30 610064 600 600 300 1.5 1.5 2 D 3 1150 550
EKDB8 12080/20 610065 800 800 20 1.5 1.5 2 F 3 1150 750
EKDB8 12080/25 610066 800 800 250 1.5 1.5 2 F 3 1150 750
EKDB8 12080/30 610067 800 800 300 1.5 1.5 2 F 3 1150 750
EKDB8 12080/40 610068 800 800 400 1.5 1.5 2 F 3 1150 750
EKDB8 120100/25 610069 1000 1000 250 1.5 1.5 2 G 3 1150 750
EKDB8 120100/30 610070 1000 1000 300 1.5 1.5 2 G 3 1150 950
EKDB8 120100/40 610071 1000 1000 400 1.5 1.5 2 G 3 1150 950
EKDB8 14060/30 610072 600 600 300 1.5 1.5 2 D 3 1350 550
EKDB8 14080/30 610073 800 800 300 1.5 1.5 2 F 3 1350 750
EKDB8 14080/40 610074 800 800 400 1.5 1.5 2 F 3 1350 750
EKDB8 140100/30 610075 1000 1000 300 1.5 1.5 2 G 3 1350 950
EKDB8 140120/30 610076 1200 1200 300 1.5 1.5 2 G 3 1350 1150
