EKEPCB1 Model 2 Protable EV Charger Controller Board

EKEPCB1 Model 2 Protable EV Charger Controller Board

EKEPCB1 PCB charge controller board using for Mode 2 level 1 Protable Charger

Inquire NOW PDF
EKEPCB1 Model 2 Protable EV Charger Controller Board

EKEPCB1 Model 2 Protable EV Charger Controller Board

Inquire NOW PDF

Product Profile

EKEPCB1 is using for mode 2 portable EV charger complies with IEC61851-1 or SAEJ1772 standard, input voltage is 230V~,

max current up to 32A, charging current can selection, it has functional of status indicating,

LCD display, charging time reservation, free PE connection, protection of over temperature,

over/under voltage, over current and residual current current protection AC30mA+DC6mA.

Technical Data

Model EKEPCB1-C/S
Mode Mode 2 charging
Operating Voltage AC230V±10%,50Hz
Outputthe PWM Signal  Max:16A,6A/8A/10A/13A/16A adjustable
Max:32A,6A/8A/10A/13A/16A/20A/25A/32A adjustable
Basic Function 1:IEC62955 standard Ac 30mA and DC6mA leakage monitoring
2:Overtemperature protection
3:Overvolatge&Undervoltage protection
4:Over current protection
5:voltage,current,Power for real time monitoring
Additional Function LCD display function with a axiliary device of LCD screen
Output Auxiliary Voltage DC12V/100mA\DC5V/100mA
Ambient Temperature -40℃-+50℃
Humidity <=85%
Colling Method Natural cooling
Installation Method PCB mounted
